Name: Automatic HDPE Jacket Pipe Production Line for Pre-Insulated Heating Pipes
Brand: Qingdao Huashida Machinery Co., Ltd.
SKU: 110-2200MM
Price: 1507500.00 USD
Availability: InStock

Automatic HDPE Jacket Pipe Production Line for Pre-Insulated Heating Pipes

MOQ

US$200,000.00-1,000,000.00

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Calibration Method: Vacuum And Water Spraying Cooling

Raw Material: PE

Screw No.: Single-screw

Cutting Method: Chipless Cutting

Application: For Producing Pre-Insulated Pipe Jacket

Highlight:

Automatic HDPE jacket pipe production line

Pre-insulated heating pipe production line

HDPE pipe production line with warranty

Basic Infomation

Place of Origin: QINGDAO,CHINA

Brand Name: HUASHIDA

Certification: CE, ISO9001:2008

Model Number: 110-2200MM

Payment & Shipping Terms

Packaging Details: Standard Package

Delivery Time: 60DAYS

Payment Terms: L/C,D/P,T/T

Supply Ability: 100 Unit/Year

Gallery

Automatic HDPE Jacket Pipe Production Line for Pre-Insulated Heating Pipes

Product Description

Automatic HDPE Jacket Pipe Production Line for Pre-Insulated Heating Pipes

Automatic HDPE Jacket Pipe Production Line for Pre-Insulated Heating Pipes is high-efficiency equipment with high speed and energy saving for producing HDPE pipe used as protective cover of PU foam thermal Pre-insulated Pipe according to international standard.This series of production lines integrates extrusion, vacuum calibration, cooling, haul-off, cutting, and unloading into a single unit.
HDPE jacket pipe are produced by vacuum calibration method, with smooth inner and outer walls, long service life, good Anticorrosion and heat preservation performance, and excellent mechanical properties.

Style	PE-110/500	PE-655/1380	PE-960/1860	PE-1155/2200
Main Extruder	SJ-75/33	SJ-120/33	SJ-150/33	SJ-150/33
Pipe diameter	Φ110-600mm	Φ655-1380mm	Φ960-1860mm	Φ1155-2200mm
Capacity	250-350kg/h	700-900kg/h	1000-1200kg/h	1350kg/h
Installed power	160kw	480kw	580kw	650kw
Length	26m	36m	45m	45m

Production line composition:

-1set   Vacuum loader
-1set   Hopper dryer
-1set   High-efficiency single screw extruder
-1set   Vacuum calibration table
-1set   Water spraying tank
-1set   Hauling machine
-1set   Cutting machine
-1set   Discharging Frame
-1set PLC (Computer control system)

Features of the HDPE sleeve production line:

1.small dimension
2.high degree of automation, can be operated by one person, saving labor costs
3.long service life.
4.high-efficiency extruder gives larger output, stable performance
5.pipe wall is average and smooth
6.no waste of raw material
7.once forming. No need trim edge.

The advantages of our company:

-Supply full completed production solution: design, installation, commissioning,training
-Share you 389 sets of production experience from all the world
-Having 9 professional senior engineers
-Having a high-end plastic machinery equipment expert workstation in China
