Name: Radiation Cross-Linked PE Heat Shrink Sleeve for 3LPE Pipeline Field Joint Repair
Brand: Qingdao Huashida Machinery Co., Ltd.
SKU: HSD
Price: 1,507,500.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Epoxy Primer Strength: ≥5.0MPa (Tested: 12MPa)

Adhesive Shear: ≥1.0MPa (Tested: 1.5MPa)

Peeling Strength: 70N

Tensile Strength: ≥17MPa (Tested: 19.47MPa)

Elongation: ≥400% (Tested: 626%)

Vicat Softening Point: ≥90°C (Tested: 92°C)

Highlight:

Radiation cross-linked PE heat shrink sleeve

3LPE pipeline field joint repair sleeve

Heat shrinkable sleeve for pipeline repair

Basic Infomation

Place of Origin: Qingdao, China

Brand Name: Huashida

Certification: CE, ISO

Model Number: HSD

Payment & Shipping Terms

Packaging Details: 2000cm*220cm*150cm

Delivery Time: 15-30 Days

Payment Terms: L/C,T/T

Supply Ability: 1000PCS/Day

Gallery

Radiation Cross-Linked PE Heat Shrink Sleeve for 3LPE Pipeline Field Joint Repair

Product Description

Radiation Cross-Linked PE Heat Shrink Sleeve for 3LPE Pipeline Field Joint Repair

Product Overview

Radiation Cross-Linked PE Heat Shrink Sleeve for Pre-Insulated Pipe Girth Weld Joint

Our high-performance radiation cross-linked PE heat shrink sleeve is a professional pre-insulated pipe girth weld joint protection material, specially developed for sealing and anti-corrosion of district heating pre-insulated pipe joints, chilled water distribution pipeline joints and PU foam insulated steel pipe girth weld connections.

As mainstream field joint coating material for buried pre-insulated pipeline projects widely used in Russia, Central Asia and Middle-East markets, this heat shrink sleeve solves joint water-ingress risks for underground heating networks.

Adopting premium two-layer composite structure: radiation cross-linked polyethylene backing (tensile strength 19.47 MPa, elongation 626%) compounded with high-adhesion imported hot-melt adhesive (peel strength 145.6N/cm to steel). It forms a seamless integrated protective barrier, keeping the same thermal-insulation and anti-corrosion performance as factory-produced pre-insulated pipe sections.

Key Characteristics

Purpose-Built for Pre-Insulated Pipe Girth Weld Joint Sealing - Engineered for harsh working conditions, blocks groundwater infiltration, preserves PU foam thermal-insulation integrity and delivers durable anti-corrosion for exposed carrier steel pipe at pipeline joints.
Fast & Simple On-Site Pre-Insulated Pipe Joint Installation - User-friendly torch-heating only field installation, no complicated special equipment or heavy surface grinding required.
Factory-Equivalent Pre-Insulated Pipe Joint Protection Standard - Matched with non-solvent two-component epoxy primer, builds solid gap-free protective enclosure for every girth-weld joint.

Core Product Benefits

Pre-Insulated Pipe Girth Weld Waterproofing

Reliably seals district-heating and chilled-water pre-insulated pipe girth-weld joints against underground water intrusion.

Excellent Chemical Anti-Corrosion Resistance

Resists erosion from 10% HCl, NaOH, NaCl and various complex underground corrosive media.

Wide Extreme-Temperature Adaptability

Vicat softening point ≥90°C; brittleness temperature <-65°C. Performs steadily in high-temperature and frigid cold-climate regions.

Superior Electrical Insulation Property

Dielectric strength ≥25MV/m; volume resistivity ≥1×10¹³Ω*m. Fully compatible with cathodic-protection systems.

Long-Term Thermal-Ageing Resistance

Maintains stable physical property under long-term buried district-heating pipeline service.

Wide Compatibility

Fits black & yellow HDPE jacket pre-insulated pipes, PU-foam insulated steel pipes, and all mainstream district-heating pipeline girth-weld joint connection forms.

Applications

District-Heating Pre-Insulated Pipe Girth-Weld Joint Sealing - Primary application for buried district-heating networks
Chilled-Water Pre-Insulated Pipe Joint Protection - For condensation-prone working conditions
Petroleum-Product Transmission Steel-Pipe Field-Joint Coating - Delivers 3LPE-equivalent anti-corrosion protection
3LPE / 2LPE Anti-Corrosion Coated Steel-Pipe Weld-Joint Repair - Restores complete anti-corrosion system
Municipal Drainage Corrugated-Pipe Joint Anti-Corrosion Wrapping - Provides waterproof and anti-corrosion joint protection

Application Scenarios

Field joint coating of steel pipe with 3LPE coating

Sealing pre-insulated pipe

Connecting and sealing drain pipes

Technical Parameters

Back Material Properties

NO	Test Item	Unit	Performance	Test Result	Test Method
1	Tensile Strength	MPa	≥17	19.47	ASTM D638
2	Elongation	%	≥400	626	ASTM D638
3	Vicat Softening Point	ºC	≥90	92	ASTM D1525
4	Brittleness Temperature	ºC	<-65	<-65	ASTM D2671C
5	Dielectric Strength	MV/m	≥25	33.13	ASTM D149
6	Volume Resistivity	Ω.m	≥1*10¹³	1.1*10¹³	ASTM D257
7	Environment Stress Crack	h	≥1000	>1000	GB/T1842

Chemical Resistance (7d)

Chemical	Property	Unit	Performance	Test Result	Test Method
10% HCI	Tensile strength	MPa	≥85	104.9	ASTM D638
10% HCI	Elongation	%	≥85	96.3	ASTM D638
10% NaOH	Tensile strength	MPa	≥85	102.1	ASTM D638
10% NaOH	Elongation	%	≥85	95.6	ASTM D638
10% NaCl	Tensile strength	MPa	≥85	108.3	ASTM D638
10% NaCl	Elongation	%	≥85	94.1	ASTM D638

Adhesive Properties

NO.	Test Item	Unit	Performance	Test Result	Test Method
1	Softening Point	ºC	≥90	90.1	ASTM E28
2	Brittleness Temperature	ºC	<-15	<-15	ASTM D2671C
3	Lap Shear	MPa	≥1.0	1.5	ASTM D1002
4	Peel Strength (23±2ºC) to Steel	N/cm	≥70	145.6	ASTM D1000
	Peel Strength to Primer	N/cm	≥70	205.9	ASTM D1000
	Peel Strength to PE layer	N/cm	≥70	190.0	ASTM D1000
5	Shear of cured primer	MPa	≥5.0	12	SY/T0041

Ordering Information

Three available supply styles for radiation cross-linked PE heat shrink sleeve for pre-insulated pipe girth-weld joint protection:

Pre-cut sleeve with separate closure patch: Standard solution for most district-heating & chilled-water pre-insulated pipe girth-weld joint projects
Pre-cut sleeve with pre-attached integrated closure patch: Single-component design for faster on-site joint installation
Continuous heat-shrink sleeve roll (closure patch ordered separately): Suitable for high-volume projects requiring custom on-site cutting

Available Specifications

Thickness: 1.2mm, 1.6mm, 1.8mm, 2.0mm, 2.5mm
Width: 100mm, 200mm, 300mm, 500mm, 600mm, 900mm
Roll length: 30m or 50m per roll
Custom dimensions available for large-volume pre-insulated pipe girth weld joint projects

Heat Shrink Sleeve Equipment: Qingdao Huashida independently designs and manufactures full sets of radiation cross-linked PE heat shrink sleeve production line equipment - available as a complete turnkey package alongside finished sleeves for pre-insulated pipe girth weld joint protection.

Company Profile

Qingdao Huashida Machinery Co., Ltd. is an experienced manufacturer with 21-year industry experience. We focus on pre-insulated pipe girth-weld joint protection materials including radiation cross-linked PE heat-shrink sleeves for district heating & chilled water pipelines, electrofusion joint sleeves, cold-applied PE anti-corrosion tapes, as well as full series plastic pipe extrusion equipment, municipal pipeline machinery, pre-insulated pipe production lines and steel pipe anti-corrosion coating lines.

Our Main Products Include:

Radiation Cross-Linked PE Heat Shrink Sleeves for pre-insulated pipe girth-weld joints
HDPE jacket pre-insulated pipe production line (110-2200mm)
Rigid PUR spray PE wrapping pre-insulated pipe production line (508-1620mm)
Flexible PERT pre-insulated pipe production line
Steel pipe FBE / 2LPE / 3LPE anti-corrosion coating lines (36-4200mm)
Turnkey cold-applied PE anti-corrosion tape production lines
PE pressure-pipe / water gas supply pipe extrusion lines
Pipeline anti-corrosion consumables

International Presence: We have successfully collaborated with over 400 international customers, exporting to Kazakhstan, Uzbekistan, Iran, Turkey, Russia, Nigeria, and 60+ countries worldwide.
