Features

Specifications

Surface Treatment: Chrome

Application: Pipeline Antocorrosion Joint

Thickness: 2.0/2.5/3.5mm

Transport Package: Standard Package

Connection: Welding

Head Type: Round

Width: 450/500

Delivery Time: 7-10days

Specification: EN253,EN448,EN728,ISO1133,ISO8501-1.ISO9001

Highlight:

HDPE heat shrinkable sleeve

corrosion resistant waterproof sleeve

EN253 certified pipeline sleeve

Basic Infomation

Place of Origin: china

Brand Name: huashida

Certification: CE, ISO9001:2008, QS, GMP

Payment & Shipping Terms

Packaging Details: Standard packaging

Delivery Time: 60 days

Payment Terms: L/C,D/A,D/P,T/T,Western Union

Supply Ability: 100set a year

Gallery

HUASHIDA HDPE Corrosion Resistant Waterproof Heat Shrinkable Sleeve for Pipeline Joints EN253 Certified

Product Description

HUASHIDA HDPE Corrugated Pipeline Joint Heat Shrink Sleeve

Corrosion resistant, waterproof, EN253 certified heat shrinkable sleeve for pre-insulation pipe joints.

Product Introduction

Developed and manufactured by Qingdao Huashida Plastic Co., Ltd., these heat shrinkable tubes are designed for pipeline anti-corrosion applications including oil & gas steel pipelines and metal reinforced HDPE corrugated pipelines.

Our company provides both heat shrinkable sleeves and heat shrinkable sleeve equipment.

The HSS (Heat Shrink Sleeve) is composed of radiation cross-linked polyethylene backing and high shearing strength adhesive.

Application Areas

Oil and gas pipelines
Inspection wells and drainage pipes (metal reinforced PE spiral pipe, hollow wall spiral pipe, etc.)
Thermo insulated pipes
3PE/2PE steel pipes
Pipe joint wrapping and anti-corrosion
Pipe repair applications

Execution Standards

GB/T23257-2009
SY/T4054-2003
EN12068
DIN30672
ASTM1000

Product Parameters - Back Material

No.	Text Item	Unit	Performance	Text Result	Text Method
1	Tensile Strength	MPa	≥17	19.47	ASTM D638
2	Elongation	%	≥400	626	ASTM D638
3	Vicat Softening Point	ºC	≥90	92	ASTM D1525
4	Brittleness Temperature	ºC	<-65	<-65	ASTM D2671C
5	Dielectric Strength	MV/m	≥25	33.13	ASTM D149
6	Volume Resistivity	Ω.m	≥1×10¹³	1.1×10¹³	ASTM D257
7	Environment Stress Crack	h	≥1000	>1000	GB/T1842

Chemical Resistance (7d)

Chemical	Property	Unit	Performance	Text Result	Text Method
10% HCI	Tensile strength	MPa	≥85	104.9	ASTM D638
10% HCI	Elongation	%	≥85	96.3	ASTM D638
10% NaAH	Tensile strength	MPa	≥85	102.1	ASTM D638
10% NaAH	Elongation	%	≥85	95.6	ASTM D638
10% NaCL	Tensile strength	MPa	≥85	108.3	ASTM D638
10% NaCL	Elongation	%	≥85	94.1	ASTM D638

Thermal Aging (150ºC, 168h)

Property	Unit	Performance	Text Result	Text Method
Tensile strength	MPa	≥14	20.7	ASTM D638
Elongation	%	≥300	630	ASTM D638

Adhesive Properties

Text Item	Unit	Performance	Text Result	Text Method
Softening Point	ºC	≥90	90.1	ASTM E28
Brittleness Temperature	ºC	<-15	<-15	ASTM D2671C
Lap Shear	MPa	≥1.0	1.5	ASTM D1002
Peel Strength (23±2ºC) - Steel	N/cm	≥70	145.6	ASTM D1000
Peel Strength (23±2ºC) - Primer	N/cm	≥70	205.9	ASTM D1000
Peel Strength (23±2ºC) - PE Layer	N/cm	≥70	190.0	ASTM D1000

Non-Solvent Epoxy Primer

Text Item	Unit	Performance	Text Result	Text Method
Shear of cured primer	MPa	≥5.0	12	SY/T0041

Construction Case: Oil & Gas Pipeline

Specification of Heat Shrinkable Sleeve for Underground Buried Steel Pipe and Insulated Pipe

No.	Size, mm	Length, mm	Patch
1	Ф159×500	670	80
2	Ф219×500	860	100
3	Ф273×500	1000	100
4	Ф325×500	1200	100
5	Ф355×500	1300	100
6	Ф406×500	1460	120
7	Ф508×500	1800	120
8	Ф610×500	2170	120
9	Ф711×500	2500	150
10	Ф813×500	2880	150
11	Ф1016×500	3480	150
12	Ф1219×500	4120	200
13	Ф1420×500	4780	200

About Qingdao Huashida Machinery Co., Ltd

Qingdao Huashida Machinery Co., Ltd is one of the top manufacturers of plastic extrusion machines in China, specializing in steel pipe anti-corrosion and insulation technology.

The company focuses on R&D of coating techniques, design and manufacture of coating equipment, products and materials, and research and development of plastic extrusion equipment.

Specialized Equipment

Vacuum Calibrating method PE insulation jacket pipe extrusion line
PE hollow wall spiral pipe production line
PE PP sheet extrusion line
Pipe joints and welding tools such as heat shrinkable sleeve, Electro fusion sleeve

International presence includes markets in Russia, Iran, UAE, India, Belarus, Kazakhstan and others, with nearly 50 pipeline production lines installed domestically and internationally.

HUASHIDA Factory is located in Qingdao High & New Technology Industrial Area - Qingdao Huashida Industrial Park, covering approximately 4000 square meters. The company holds more than 10 patents and numerous industry certifications both domestically and internationally.

HUASHIDA maintains high-qualified and experienced teams for research, design, manufacturing, and site operations, offering reliable products, custom solutions through outstanding R&D capabilities, and timely technical support through comprehensive after-sales service.
