Innovative PE Pre-Insulated Pipe Extrusion Line with Vacuum Calibrating

                                        Innovative PE Pre-Insulated Pipe Extrusion Line with Vacuum Calibrating

Advantages:

• Improved Pipe Properties: Vacuum calibration enhances pipe stiffness, flexibility, and mechanical strength.
• High Intelligence: The high degree of automation reduces labor costs and improves production efficiency.
• Fast Production Speed: The line is 30% faster than similar equipment, increasing throughput.
• Durability: High-quality hardware and software minimize maintenance costs.

Working Conditions:

• Electric Source: 3-phase, 380V (±10%, +5%), 50Hz
• Total Power: ~160kW
• Cooling Water: ≤20ºC, ≥0.3Mpa, 26-30 m³/h
• Compressed Air: 0.4m³/min, >0.5MPa
• Dimension: 24m x 3m x 3m
• Material: HDPE Granules

Technical Parameters:

This high-efficiency plastic pipe production line is primarily composed of nine essential parts:

The machines in the production line can be customized according to your specific requirements.

HDPE Jacket Process Flow:

Vacuum feeding PE granule-->hot air dry material-->extrusion plasticizing-->mold shaping-->Vacuum sizing-->water cooling-->Pulling out-->cutting pipe-->carrier laying-off pipe

​
