Automatic 3LPE Coating Pipe Production Line with PLC Control System and CE ISO Certification for Durable Pipeline Solutions

1 set
MOQ
150000-1000000
Price
Automatic 3LPE Coating Pipe Production Line with PLC Control System and CE ISO Certification for Durable Pipeline Solutions
Features Gallery Product Description Request A Quote
Features
Specifications
Coating Layers: 3 Layers
Control System: PLC
Pipe Surface Preparation: Shot Blasting
Heating Method: Induction Heating
Pipe Diameter Range: Φ57mm To Φ1620mm
Operating Mode: Automatic
Highlight:

Automatic 3LPE coating pipe production line

,

PLC control 3LPE pipe production line

,

CE ISO certified 3LPE coating line
Basic Infomation
Place of Origin: China
Brand Name: Huashida
Certification: CE, Rohs，TUV
Model Number: 001
Payment & Shipping Terms
Packaging Details: Container loading，sea transportation
Delivery Time: 60work days
Payment Terms: T/T,Western Union,D/A
Supply Ability: 5-10 +sets+per mouth
Product Description
3 Layer Polyethylene (3LPE) Anti-Corrosion Steel Pipe Production Line for Oil & Gas
Product Overview

Huashida 3LPE steel pipe blasting & coating equipment is designed for water, gas, and oil pipeline anti-corrosion processing according to customers' specific requirements. The production line includes internal and external shot blasting for derusting, dual Fusion Bonded Epoxy (FBE) powder or liquid coating, PE/PP film wrapping, PE end grooving system, and more.

Automatic 3LPE Coating Pipe Production Line with PLC Control System and CE ISO Certification for Durable Pipeline Solutions 0
Key Advantages
High Quality, Competitive Price, and Excellent Service

Huashida's 3PE anti-corrosion coating production line features superior equipment quality, an affordable price, and outstanding service. The three-layer PE pipelines produced using this production line rank at the forefront of the oil and gas transportation industry.

Comprehensive Production Process
  • Pipe loading
  • External derusting
  • Inner blowing cleaning
  • Epoxy coating application
  • Adhesive application on the epoxy layer
  • PE jacket coating
  • Water cooling
  • Coating layer inspection
  • Pipe edge treatment
  • Finished pipe conveyance
  • Pipe unloading
Technical Specifications
Automatic 3LPE Coating Pipe Production Line with PLC Control System and CE ISO Certification for Durable Pipeline Solutions 1 Automatic 3LPE Coating Pipe Production Line with PLC Control System and CE ISO Certification for Durable Pipeline Solutions 2 Automatic 3LPE Coating Pipe Production Line with PLC Control System and CE ISO Certification for Durable Pipeline Solutions 3
Wide Diameter Range

The 3PE anti-corrosion coating production line can handle pipes with diameters ranging from Φ57mm to Φ1620mm, enabling one-stop pipeline operations.

Three-Layer PE Anti-Corrosion Structure

The three-layer PE anti-corrosion structure combines the excellent anti-corrosion properties of epoxy coatings and extruded polyethylene. The epoxy coating offers superior interface characteristics and chemical resistance, while the extruded polyethylene coating provides excellent mechanical protection.

  • First Layer: Epoxy powder (FBE > 100µm) - provides basic anti-corrosion protection
  • Second Layer: Adhesive (AD) with thickness of 170-250µm - acts as bonding agent
  • Third Layer: Polyethylene (PE) with thickness of 2.5-3.7mm - offers robust mechanical protection

This anti-corrosion structure integrates the three materials into one and forms an excellent anti-corrosion layer firmly bonded to the steel pipe. After years of practical application, the buried three-layer outer protective layer has proven to be highly superior with a service life of over 50 years.

Automatic 3LPE Coating Pipe Production Line with PLC Control System and CE ISO Certification for Durable Pipeline Solutions 4 Automatic 3LPE Coating Pipe Production Line with PLC Control System and CE ISO Certification for Durable Pipeline Solutions 5 Automatic 3LPE Coating Pipe Production Line with PLC Control System and CE ISO Certification for Durable Pipeline Solutions 6
Equipment Configuration
Steel Pipe Outside Shot Blasting Derusting Operation Line
No. Description Qty. Remarks
1 Transmission line 1 set
2 Shot blasting derusting line 1 set
3 Cyclone dust collector 1 set
4 Pulse filter cartridge dust collector 1 set
5 Centrifugal wind blower 1 set
6 Derusting equipment electrical control system 1 set
Steel Pipe Outside Spiral 3PE Production Line
No. Description Qty.
1 Coating transmit system 1 set
2 Intermediate frequency heating system 1 set
3 Epoxy spraying system 1 set
4 Automatic feeding dryer 2 sets
5 SJ-65/30 single screw high efficiency extruder 1 set
6 SJ-120/30 extruder 1 set
7 Hot melt adhesive extrusion die head 1 set
8 PE sheet extrusion die head 1 set
9 Hot melt adhesive/PE sheet press device 1 set
10 Stainless steel spray powder chamber 1 set
11 Cooling water spray system 1 set
Platform System
No. Description Qty.
1 Steel pipe up load platform 1 set
2 Derusting transition platform 1 set
3 Finished pipe storage system 1 set
4 Hydraulic system 3 sets
Grooving System
No. Description Qty.
1 PE grooving device 2 sets
2 Hydraulic elevating pipe turner 2 sets
3 Operating cabinet 1 set
Frequently Asked Questions
Q: What is the brand name of this 3LPE Coating Pipe Production Line?
A: The brand name of this product is Huashida.
Q: What is the model number of this 3LPE Coating Pipe Production Line?
A: The model number of this product is 50-4200mm.
Q: Where is this 3LPE Coating Pipe Production Line manufactured?
A: This product is manufactured in Qingdao, China.
Q: What certifications does this 3LPE Coating Pipe Production Line have?
A: This product is certified with ISO, CE, and RoHS certifications.
Q: What is the minimum order quantity for this 3LPE Coating Pipe Production Line?
A: The minimum order quantity for this product is 1 set.
Manufacturer Profile
Qingdao Huashida Machinery Co., Ltd.

Founded in 2003, Qingdao Huashida Machinery Co., Ltd. is a professional manufacturer specializing in:

  • Plastic extrusion equipment
  • Steel pipe anti-corrosion coating lines
  • Pipe insulation machinery
  • Municipal pipeline equipment

With customers across Europe, America, the Middle East, Central Asia, and Southeast Asia, Huashida has become a trusted supplier in the global pipeline industry.

Why Choose Huashida?
  • More than 20 years of manufacturing experience
  • Advanced technology and stable quality
  • Professional engineering team
  • Complete installation and training services
  • Global export experience

Welcome to visit our factory and explore long-term cooperation opportunities.

Automatic 3LPE Coating Pipe Production Line with PLC Control System and CE ISO Certification for Durable Pipeline Solutions 7 Automatic 3LPE Coating Pipe Production Line with PLC Control System and CE ISO Certification for Durable Pipeline Solutions 8 Automatic 3LPE Coating Pipe Production Line with PLC Control System and CE ISO Certification for Durable Pipeline Solutions 9 Automatic 3LPE Coating Pipe Production Line with PLC Control System and CE ISO Certification for Durable Pipeline Solutions 10
