Name: Sa2.5 Steel Pipe Outer Wall Shot Blasting Abrator Blaster line
Brand: Qingdao Huashida Machinery Co., Ltd.
SKU: Rotary Abrator Blaster
Price: 1,507,500.00 USD
Availability: InStock

Sa2.5 Steel Pipe Outer Wall Shot Blasting Abrator Blaster line

MOQ

US$100,000.00-180,000.00

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Cleaning Level: ≥SA 2.5

Steel Pipe Diameter Range: 60mm-4200mm

Used Material: Steel Sand, Steel Shot, Steel Wire Segment, Etc

Function: Steel Pipe Shot Blasting

Highlight:

Sa2.5 steel pipe shot blaster

outer wall shot blasting machine

3LPE coating pipe production equipment

Basic Infomation

Place of Origin: QINGDAO,CHINA

Brand Name: huashida

Certification: CE

Model Number: Rotary Abrator Blaster

Payment & Shipping Terms

Packaging Details: Standard Packaging

Delivery Time: 60days

Payment Terms: L/C,D/P,T/T

Supply Ability: 30 Units/Year

Gallery

Sa2.5 Steel Pipe Outer Wall Shot Blasting Abrator Blaster line

Product Description

Sa2.5 Steel Pipe Outer Wall Shot Blasting Abrator Blaster line

Sa2.5 Steel Pipe Outer Wall Shot Blasting Abrator Blaster line

The high-speed Shots (steel shots, steel sand, etc.) are casted to the outer surface of the steel pipe by shot blasters. The Shots hit the surface of the steel pipe with a strong impact force to make the rust, scale and other impurities fall off to achieve the purpose of rust removal.

introduction
This method has high rust removal efficiency and can quickly remove the stubborn rust layer on the surface of the steel pipe, and at the same time of rust removal, the impact of the shots can also produce a certain crushing stress on the surface of the steel pipe, improve the power of resist fatigue strength and corrosion resistance of the steel pipe.

Production line parameters:

(1)Steel pipe diameter range:60mm-4200mm

(2)Processing capacity:≥400㎡/h

(3)Cleaning level:Sa2.5 class

(4)Used material: Steel sand, steel shot, steel wire segment, etc

(5)Main equipment: Cleaning room, Shot blaster , conveyor, pipe uploading mechanism, pipe downloading mechanism, spiral conveyor, elevator, maintenance platform, separator, dust removal system and electric control system.

Sa2.5 Steel Pipe Outer Wall Shot Blasting Abrator Blaster line 0

Features

The production line includes the following equipment

No.	Equipment	Quantity
1	Steel pipe rack	1 set
2	Steel pipe on-line ferry mechanism	2 sets
3	Hydraulic station 1 for 2	2 sets
4	Conveyor system	1 set
5	Shot blasting machine	1 unit
6	Cyclone dust collector	1 unit
7	Pulse filter cartridge dust collector	1 unit
8	Centrifugal induced draft fans	1 unit
9	Electrical control system	1 set
10	Steel pipe offline rack	1 set
1 1	Steel pipe offline ferry mechanism	2 sets

Outer Wall Shot Blasting machine

Sa2.5 Steel Pipe Outer Wall Shot Blasting Abrator Blaster line 1

Sa2.5 Steel Pipe Outer Wall Shot Blasting Abrator Blaster line 2

Sa2.5 Steel Pipe Outer Wall Shot Blasting Abrator Blaster line 3

Qingdao Huashida Machinery Co., LTD., founded in 2003, is a global developer, manufacturer and solution provider of plastic extrusion equipment. 70% of its customers come from overseas countries such as Europe, America, the Middle East and Southeast Asia.
Welcome to our factory to discuss cooperation!

Our Main Products Include:
HDPE Jacket Pipe Extrusion Line
3LPE Steel Pipe Anti-Corrosion Coating Line
Hollow Wall Spiral Pipe Production Line
PE/PP Geo Membrane Production Line
PE/PP Sheet Board Extrusion Line
Rubber Foam Insulation Pipe Production Line
Radiation Cross-Linked PE Heat Shrinkable Sleeve
Electro Fusion Sleeve
Portable Hand Extrusion Welder
HDPE Welding Wire Welder Rods

Sa2.5 Steel Pipe Outer Wall Shot Blasting Abrator Blaster line 4

Sa2.5 Steel Pipe Outer Wall Shot Blasting Abrator Blaster line 5

Sa2.5 Steel Pipe Outer Wall Shot Blasting Abrator Blaster line 6
