Customized Automatic 3LPE Coating Pipe Production Line for Large-Diameter Steel Pipes

1 set
MOQ
150000-1000000
Price
Customized Automatic 3LPE Coating Pipe Production Line for Large-Diameter Steel Pipes
Features Gallery Product Description Ratings & Review Request A Quote
Features
Specifications
Coating Layers: 3 Layers
Control System: PLC
Pipe Surface Preparation: Shot Blasting
Origin: China
Connection Type: Welding
Operating Mode: Automatic
Coating Structure: Fbe, 2lpe, 3lpe
Coating Type: Internal, External
Heating Method: Induction Heating
Certification: CE, ISO, RoHS, REACH
Highlight:

Customized 3LPE Coating Pipe Production Line

,

Large-Diameter Steel Pipe Anti-Corrosion Production Line

,

Automatic 3 Layer Polyethylene Pipe Production Line
Basic Infomation
Place of Origin: China
Brand Name: Huashida
Certification: CE, Rohs，TUV
Model Number: 001
Payment & Shipping Terms
Packaging Details: Container loading，sea transportation
Delivery Time: 60work days
Payment Terms: T/T,Western Union,D/A
Supply Ability: 5-10 +sets+per mouth
Product Description

Product Description


Customized Automatic 3LPE Coating Pipe Production Line for Large-Diameter Steel Pipes 0
Product Description
3LPE (Three-Layer Polyethylene) coated steel pipes consist of a multi-layered structure designed for superior corrosion resistance and durability. The structure includes:
First Layer: Fusion-bonded epoxy (FBE) for strong adhesion to the steel and excellent corrosion protection
Second Layer: Copolymer adhesive for bonding the epoxy and PE layer
Third Layer: High-density polyethylene (HDPE) for mechanical protection
This three-layer coating is widely recognized as one of the most effective anti-corrosion systems for buried steel pipelines.
Customized Automatic 3LPE Coating Pipe Production Line for Large-Diameter Steel Pipes 1
Customized Automatic 3LPE Coating Pipe Production Line for Large-Diameter Steel Pipes 2
Advantages of 3LPE Coated Pipes
 Exceptional Sealing Performance: Reduces energy loss, minimizes maintenance, and extends pipeline life
High Corrosion Resistance: Withstands harsh environments with a service life of 30–50 years
Low-Temperature Impact Resistance: Maintains flexibility and toughness even in cold climates
Excellent Bonding: Combines high epoxy strength, low PE water absorption, and strong adhesive softness
Reliable & Cost-Effective: Simplified production process, low cost, and excellent anti-corrosion effect
Versatile Application: Suitable for gas, oil, water, and other fluid transportation pipelines.
Customized Automatic 3LPE Coating Pipe Production Line for Large-Diameter Steel Pipes 3
Customized Automatic 3LPE Coating Pipe Production Line for Large-Diameter Steel Pipes 4
Customized Automatic 3LPE Coating Pipe Production Line for Large-Diameter Steel Pipes 5
Please enter the title here
Technical Parameters
Pipe Diameter Range: 50–4200 mm
Production Capacity: ≥250 m²/h
Surface Cleaning Level: ≥Sa 2.5
Materials Used: Epoxy powder, copolymer adhesive, polyethylene
Customized Automatic 3LPE Coating Pipe Production Line for Large-Diameter Steel Pipes 6
Customized Automatic 3LPE Coating Pipe Production Line for Large-Diameter Steel Pipes 7
Please enter the title here
Application Fields
The 3LPE coating line is widely applied in:
Oil and gas transportation pipelines
Urban gas distribution networks
Water supply systems
Industrial fluid pipelines
Company Profile
Main Equipment List
No.
Name
Set
A. Derusting Equipment
1
Pipe wheel conveyor
1
2
Shot Blasting Machine
1
3
Cyclone Dust Collector
1
4
Pulse dust collector
1
5
Centrifugal exhaust fan
1
6
Rust removal equipment PLC
1
B. Coating equipment
1
Pipe wheel conveyor
1
2
Induction heating device
1
3
Powder spraying device
1
4
Automatic loading dryer
2
5
SJ-65/30 Extruder
1
6
SJ-120/30 Extruder
1
7
Hot melt adhesive extruder die
1
8
PE sheet extruder head mold
1
9
Hot melt adhesive/PE sheet coating device
1
10
Environmental Protection Ventilation equipment
1
11
Cooling Spray equipment
1
C.Platform Equipment
1
Steel pipe uploading platform
1
2
Downloading platform
1
3
Pipe storage platform
1
4
Turnover machanism
3
D.Groove Equipment
1
PE Beveling Machine
2
2
Hydraulic Lifting and Turning Machinery
1
3
Hydraulic Equipment
1
4
PLC automatic control system
1

Qingdao Huashida Machinery Co., LTD, is a manufacturer of series of plastic pipe machines, municipal pipe machines, pipe insulation&anticorrosion machines, and pipe jointing&anticorrosion materials, with 21 years of production experience.
Our main products are:
1. HDPE jacket pipe for pre-insulated pipe Production Line (110-2000mm)
2. Rigid pre-insulated pipe Production Line
3. Flexible pre-insulated pipe(PERT) production line
4. Steel pipe FBE/2LPE/3LPE anti-corrosion coating line
5. Steel pipe derusting line
6. PE pressure pipe/Water Gas supply pipe production line
6. PP/PE plastic board/sheet/geomembrane production line
7. NBR PVC Thermal insulation tube/plate production line
8.Pipeline anti-corrosion materials and instruments: heat shrink joint coating sleeve, electro-fusion weldable joint sleeve, portable welding gun(extruder), PE PP welding rod.

We have been working with more than 400 overseas customers and exporting our products to Kazakhstan, Uzbekistan, Iran, Turkey, Russia, Nigeria and other countries
