High Automation Precision Engineering Energy Efficient Pipeline Jacket Casing Production Line for Steel Pipes

A Pipeline Jacket Casing Production Line for Steel Pipes is an advanced industrial system designed to produce protective outer casings (jackets) that surround steel pipelines, enhancing their durability, insulation, and resistance to environmental damage. This production line is widely used in industries such as oil & gas, district heating, water supply, and chemical transport. It manufactures high-quality outer layers—typically made from HDPE (High-Density Polyethylene) or similar thermoplastic materials—that act as a shield for steel pipes against corrosion, moisture, and mechanical impact.

• High Automation: PLC-control systems ensure consistent quality and reduced labor
• Precision Engineering: Uniform thickness and diameter for reliable pipe protection
• Energy Efficient: Optimized heating and cooling systems reduce energy consumption
• Customizable Design: Suitable for different pipe diameters and coating requirements

1. Raw Material Feeding: Plastic granules (usually HDPE) are loaded into the system
2. Extrusion System: The material is melted and extruded through a die to form a continuous plastic pipe or casing
3. Vacuum Calibration & Cooling: The extruded casing is shaped and cooled to achieve accurate dimensions and smooth surface finish
4. Haul-Off Unit: The casing is continuously pulled at a controlled speed
5. Cutting or Winding System: Finished casings are cut into required lengths or coiled for storage and transport

• Small dimension
• High degree of automation, can be operated by one person, saving labor costs
• A long service life
• High-efficiency extruder gives larger output, stable performance
• Pipe wall is average and smooth
• No waste of raw material
• Once forming. No need trim edge
• Supply full completed production solution: design, installation, commissioning, training
• Share you 390 sets of production experience from all the world
• Having 13 professional senior engineers
• Having a high-end plastic machinery equipment expert workstation in China

• Pre-insulated Pipes (district heating & cooling systems)
• Oil & Gas Pipelines (anti-corrosion outer layer)
• Water Transmission Systems
• Underground & Offshore Pipelines

• Extends pipeline service life
• Provides excellent corrosion and UV resistance
• Enhances mechanical protection during installation and operation
• Improves thermal insulation performance when used with foam layers

Qingdao Huashida Machinery Co., LTD, is a manufacturer of series of plastic pipe machines, municipal pipe machines, pipe insulation & anticorrosion machines, and pipe jointing & anticorrosion materials, with more than 20 years of production experience.

• HDPE jacket pipe for pre-insulated pipe Production Line (110-2000mm)
• Rigid pre-insulated pipe Production Line
• Flexible pre-insulated pipe(PERT) production line
• Steel pipe FBE/2LPE/3LPE anti-corrosion coating line
• Steel pipe derusting line
• PE pressure pipe/Water Gas supply pipe production line
• PP/PE plastic board/sheet/geomembrane production line
• NBR PVC Thermal insulation tube/plate production line
• Pipeline anti-corrosion materials and instruments: heat shrink joint coating sleeve, electro-fusion weldable joint sleeve, portable welding gun(extruder), PE PP welding rod

We have been working with more than 400 overseas customers and exporting our products to Kazakhstan, Uzbekistan, Middle East, Russia, Nigeria and other countries.
