Advanced Hydraulic Clamp Haul Off Machine with PLC Control for 20-160mm Pipe Range

The Advanced Haul-Off Machine (also called a traction unit) is a critical downstream component in HDPE/PE pipe extrusion lines. It is designed to continuously pull the extruded pipe from the cooling system at a controlled and synchronized speed, ensuring dimensional accuracy and surface quality.

In a typical HDPE pipe production line, the haul-off machine operates after:

• Extruder
• Vacuum calibration tank
• Cooling tank

It ensures stable pipe movement before cutting and stacking.

• Multi-pillar / multi-claw design (2-12 belts or claws)
• Rubber belt or block traction system for non-slip grip
• Hydraulic or pneumatic clamping system
• Heavy-duty frame with adjustable alignment
• AC motor-driven with frequency control

The multi-claw system distributes traction force evenly across the pipe circumference, improving stability and preventing deformation.

• Capable of handling large-diameter and thick-wall HDPE pipes
• Peak traction can reach up to 60,000 N depending on model

• Frequency inverter (ABB/Siemens) ensures synchronized speed with extrusion line
• Stepless speed regulation maintains uniform wall thickness

• Suitable for pipes from small (6 mm) to large (800+ mm diameter)

• Even distribution of pulling force reduces:
  • Pipe ovality
  • Surface defects
  • Internal stress

• Adjustable clamping for:
  • Different pipe materials (HDPE, PE, PP, PERT, and more)
  • Various wall thicknesses and diameters

• Integrated PLC control system
• Touchscreen HMI for parameter setting
• Automatic synchronization with cutter

• Low vibration and noise
• Continuous, non-stop operation for high productivity

Qingdao Huashida Machinery Co., LTD, is a manufacturer of series of plastic pipe machines, municipal pipe machines, pipe insulation & anticorrosion machines, and pipe jointing & anticorrosion materials, with more than 20 years of production experience.

• HDPE jacket pipe for pre-insulated pipe Production Line (110-2000mm)
• Rigid pre-insulated pipe Production Line
• Flexible pre-insulated pipe (PERT) production line
• Steel pipe FBE/2LPE/3LPE anti-corrosion coating line
• Steel pipe derusting line
• PE pressure pipe/Water Gas supply pipe production line
• PP/PE plastic board/sheet/geomembrane production line
• NBR PVC Thermal insulation tube/plate production line
• Pipeline anti-corrosion materials and instruments: heat shrink joint coating sleeve, electro-fusion weldable joint sleeve, portable welding gun (extruder), PE PP welding rod

We have been working with more than 400 overseas customers and exporting our products to Kazakhstan, Uzbekistan, Iran, Turkey, Russia, Nigeria and other countries.
