Product Description
External 3LPE anti-corrosion and internal epoxy liquid coating spray is a highly efficient method for protecting steel pipes from corrosion.
The external 3PE anti-corrosion structure consists of an epoxy powder primer, an adhesive middle layer, and an outer polyethylene layer. The epoxy powder primarily provides corrosion resistance, the adhesive enhances bonding between layers, and the polyethylene offers excellent mechanical protection and environmental durability.
The internal epoxy liquid coating spray provides strong adhesion and exceptional chemical corrosion resistance, effectively preventing corrosion inside steel pipes caused by conveyed media (such as oil, gas, water, etc.). This corrosion protection method is widely used in oil and natural gas transmission pipelines, water supply and drainage pipelines, and other fields, significantly extending the service life of steel pipes.
Huashida delivers high-quality, cost-effective, and innovative coating solutions-featuring internal liquid coatings and external 3LPE-designed to extend pipeline service life, lower maintenance expenses, and ensure reliable project delivery for clients across the globe.
Technological processes
Pipe Loading → Conveying → Shot Blasting (Rust Removal) → Induction Heating → FBE Coating → AD & PE Extrusion Coating → Water Cooling → Conveying → Pipe End Grinding → Unloading
Main Equipment Composition
Surface Treatment Excellence: Featuring a robust shot blasting machine, complemented by an efficient cyclone dust collector and a high-performance pulse dust remover, ensuring impeccable surface treatment.
Advanced Heating System: Utilizing state-of-the-art induction heating equipment to deliver consistent thermal energy, optimizing the coating process.
Comprehensive Coating System: Equipped with an FBE powder coating unit, an adhesive extruder, and a PE extruder, ensuring a seamless and durable coating application.
Effective Cooling System: Incorporating a water spraying and cooling device to maintain ideal temperatures and enhance coating quality.
Efficient Conveying System: Featuring a sophisticated pipe loading/unloading platform and turning rollers for smooth and seamless operations.
Intelligent Control System: Powered by a cutting-edge PLC automatic control system, delivering precise and reliable process management.
Auxiliary Equipment Excellence: Includes a PE beveling machine, a hydraulic lifting system, and a comprehensive exhaust & ventilation system to support seamless operations.
Our Advantages
Cost Reduction - Enjoy unprecedented cost-efficiency with our product, offering high sealing performance that ensures substantial energy savings while being environmentally friendly.
Long Service Life - Experience hassle-free installation and construction with our product, boasting an impressive lifespan of up to 30-50 years, ensuring long-term durability and reliability.
Excellent Impact Resistance - Our product excels in impact resistance, maintaining exceptional performance even at low temperatures, with a remarkable low water absorption rate that enhances its structural integrity.
Superior Anti-Corrosion Performance - Benefit from top-notch anti-corrosion protection through a straightforward and cost-effective process, ensuring your investment's longevity and reliability.
Fully Automatic Operation - Our advanced PLC control system, equipped with intelligent sensors, offers precise and efficient operation, meticulously monitoring position, speed, and energy levels for optimal performance.
Product Parameters
| Steel pipe outside shot blasting derusting operation line |
| No. |
Description |
Qty. |
Remarks |
| 1 |
Transmission line |
1set |
|
| 2 |
Shot blasting derusting line |
1set |
|
| 3 |
Cyclone dust collector |
1set |
|
| 4 |
Pulse filter cartridge dust collector |
1set |
|
| 5 |
Centrifugal wind blower |
1set |
|
| 6 |
Derusting equipment electrical control system |
1set |
|
| Steel pipe outside spiral 3PE production line |
| No. |
Description |
Qty. |
|
| 1 |
Coating transmit system |
1set |
|
| 2 |
Intermediate frequency heating system |
1set |
|
| 3 |
Epoxy spraying system |
1set |
|
| 4 |
Automatic feeding dryer |
2sets |
|
| 5 |
SJ-65/30 single screw high efficiency extruder |
1set |
|
| 6 |
SJ-120/30 extruder |
1set |
|
| 7 |
Hot melt adhesive extrusion die head |
1set |
|
| 8 |
PE sheet extrusion die head |
1set |
|
| 9 |
Hot melt adhesive/PE sheet press device |
1set |
|
| 10 |
Stainless steel spray powder chamber |
1set |
|
| 11 |
Cooling water spray system |
1set |
|
Platform system |
| No. |
Description |
Qty. |
|
| 1 |
Steel pipe up load platform |
1set |
|
| 2 |
Derusting transition platform |
1set |
|
| 3 |
Finished pipe storage system |
1set |
|
| 4 |
Hydraulic system |
3sets |
|
| Grooving system |
| No. |
Description |
Qty. |
|
| 1 |
PE grooving device |
2sets |
|
| 2 |
Hydraulic elevating pipe turner |
2sets |
|
| 3 |
Operating cabinet |
1set |
|
Applications
Qingdao Huashida's 3-layer PE Coated Steel Pipes are designed for a wide range of applications, including:
Oil & Gas Pipelines: Long-term protection against corrosion and damage, ensuring safe transport.
Urban Gas & Water Systems: Reliable and clean transport of essential fluids, enhancing infrastructure safety.
District Heating: Excellent insulation and corrosion resistance, even at high temperatures.
Underground & Industrial Anti-Corrosion: Robust protection for both buried and exposed pipelines.
Global Reach:
This technology is widely used in major infrastructure projects, with exports to Europe, the Middle East, Central Asia, Africa, Russia, and more.
Company Profile
Qingdao Huashida Machinery Co., LTD, a leading powerhouse in manufacturing, a diverse range ofplastic pipe machinery solutions, as well as municipal pipe machinery, along with cutting-edgepipe insulation & advanced anticorrosiontechnologies and robust machinery.We also specialize in pipe jointing &innovative anticorrosion materials,backed by over 21 years of unparalleled production excellence.
