Features

Specifications

Type: Sheet Extruder

Assembly Structure: Separate Type Extruder

Screw: Single-Screw

Engagement System: Full Intermeshing

Screw Channel Structure: Deep Screw

HS Code: 8477209000

Screw No.: Single-screw

Highlight:

three layer PE sheet extruder

PE PP board extrusion line

plastic sheet extrusion machine

Basic Infomation

Place of Origin: Qingdao ，China

Brand Name: Huashida

Certification: ISO9001: 2008

Model Number: HSD

Payment & Shipping Terms

Packaging Details: Standard package

Delivery Time: 70 -90 days

Payment Terms: L/C,T/T

Supply Ability: 50 Units/Year

Gallery

Single-Screw PE Sheet Extruder 300-7000mm Width 0.2-45mm Thickness

Product Description

Three Layer PE Sheet Boards Extrusion Line China Plastic Extruder

Basic Info.

Model NO.

HSD

Product Type

PE Board

Board Layers

Multilayer

Screw No.

Single-screw

Automation

Automatic

Computerized

Certification

CE, ISO9001:2008

Customized

Condition

New

Sheet Width

300-7000mm

Thickness

0.2-45mm

Color

by Buyer's Opinion

Extrusion System

Mono-Layer or Multi-Layer

Raw Material

ABS/PE/ PP/ PS/ Pet/PC/ PMMA

Transport Package

Wooden Cases and Pallets

Specification

CE, ISO9001: 2008, SGS

Trademark

Huashida

Origin

Qingdao, China

HS Code

8477209000

Production Capacity

20 Sets

Packaging & Delivery

Package Size

1000.00cm * 220.00cm * 180.00cm

Package Gross Weight

1000.000kg

Product Description

Three Layer PE Sheet Boards Extrusion Line China Plastic Extruder

Structure of PE Sheet Boards Extrusion Line Machine:
It consists of SBJZ-series plate &sheet special-purpose single screw extruder SJZ-series conical twin screw extruder Or SJ-series parallel twin screw extruder; Equipped with auxiliary downstream accessories and moulds, it can produce: PP, PS, HIPS, PE, ABS, EVA, PMMA, PC, PT, PVB, PVC and other board & sheet.
The machinery unit consists of extruder, Screen changing device, melt pump, T-die, 3-rollr or multiple-roller calender, cooling device, edge cutter, Haul-off system, plate cutter winder, electrical control system.
Others, The working principle is the 3 states of the hot-plastics at different temperatures: The pushing force of the screw change the physical stat from glass state to high elastic state, then glutinous-and-fluid sate, it comes out from the slim gap of the die, the rest of the procedures are calendar, cooling-shaper, edge-cutter, Haul-off, cutter, winder.
PC/PP hollow cross-section plate. PVC transparent soft & hard plat & sheet. PVC foamed plate, PMMA/ABS co-extrusion bathing plate, inside chamber plate of the refrigerator and other multiple-layer composite co-extrusion plate & sheet size: Width: 300MM-700MM thickness0.2MM-45MM: Output rate: 80-1800KG. /H. The machinery unit is the best solution for plate & sheet production.

(Modle)	(width)	Thickness(MM)	Seedtm/min)	Outputr(kg/h)
SBJZ-800	650	0.18-1.5	1-25	80-320
SBJZ -1000	800	0.2-2.0	1-20	150-430
SBJZ -1500	1350	1-10	0.5-10	150-450
SBJZ -2000	1850	2-15	0.5-8	300-550
SBJZ -2200	2000	1-10	0.4-3	420-820
SBJZ -3000	2850	2-8	0.2-3	500-1200
SBJZ -7000	6800	2-6	0.2-2	600-1560

Features of the machinery unit: High grade alloy structural steel ( 38CRMOALA) made material barrel& screw and mould, after nitriding treatment. It gets high hardness, corruption and long service life. Choice T-die the flowing passage is designed for easy flowing of thehout any detaining, and the product thickness is even, For the calender, large conical slot is designed, the cooling quality inside the roller is good, and the temperature synchronization,

Single-Screw PE Sheet Extruder 300-7000mm Width 0.2-45mm Thickness 0

Single-Screw PE Sheet Extruder 300-7000mm Width 0.2-45mm Thickness 1

Single-Screw PE Sheet Extruder 300-7000mm Width 0.2-45mm Thickness 2

Single-Screw PE Sheet Extruder 300-7000mm Width 0.2-45mm Thickness 3
