Radiation Cross Linked Polyethylene Heat Shrink Sleeve 1.5-3.5mm

The Qingdao Huashida Radiation Cross-linked Polyethylene (PE) Heat Shrink Sleeve is an advanced anti-corrosion solution designed for the field application of 3-layer polyethylene (3LPE) coating systems. It is ideal for the protection and repair of welded joints in steel pipelines used in oil, gas, and water supply systems.

This product replicates the factory-applied 3LPE structure and performance in field conditions, ensuring durable and reliable protection for pipeline joints.

The heat shrink sleeve is composed of two primary layers:

• Radiation Cross-linked Polyethylene (PE) Backing
  Offers superior mechanical strength and protection from external damage.
• Special Hot-Melt Adhesive Layer
  Ensures strong adhesion to the steel surface and seamless bonding with the epoxy primer.

This system is applied in conjunction with a solvent-free two-component epoxy primer, forming a true 3-layer field-applied coating system.

• Surface Preparation
  Clean and prepare the steel surface at the weld joint area.
• Epoxy Primer Application
  Apply the solvent-free two-component epoxy primer onto the prepared pipe surface.
• Sleeve Application
  Wrap the heat shrink sleeve over the wet primer.
• Heat Shrinking
  Apply heat to shrink the sleeve tightly around the joint. The adhesive melts and flows, filling surface imperfections and bonding the sleeve firmly to the pipe.
• Curing and Protection
  As the epoxy cures, it creates strong chemical and mechanical bonds. The outer PE layer forms a solid protective barrier against moisture and mechanical damage.

• Field joint corrosion protection for oil and gas pipelines
• Field joint corrosion protection for water pipelines
• Repair and maintenance of factory-applied 3LPE coatings

• Made with brand new PE materials and high-quality adhesive
• Strict quality control throughout production
• Fast shrinkage ensures efficient installation
• Excellent waterproof and moisture-sealing capabilities
• Superior anti-corrosion and chemical resistance
• Long operational life, even in harsh environments
• Easy to apply on-site with minimal tools
