HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection

HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Connecting And Welding Plastic Pipline
Size: According To Customer′s Requirements
Specification: EN253, EN448, EN728, ISO1133, ISO8501-1. ISO9001
HS Code: 3920999090
Highlight:

3LPE Pipeline Joint Protection Sleeve

,

HDPE Heat Shrink Sleeve

,

HDPE Heat Shrinkable Joint
Basic Infomation
Place of Origin: Qingdao，China
Brand Name: Huashida
Certification: ISO9001：2008， CE
Model Number: 1.5-3.5mm
Payment & Shipping Terms
Product Description
HDPE Pre-Insulated Pipe Field Joint Heat Shrink Sleeve
Durable & Efficient Insulation Solution
Product Introduction

The Qingdao Huashida Radiation Cross-linked Polyethylene (PE) Heat Shrink Sleeve is an advanced anti-corrosion solution designed for the field application of 3-layer polyethylene (3LPE) coating systems. It is ideal for the protection and repair of welded joints in steel pipelines used in oil, gas, and water supply systems.

This product replicates the factory-applied 3LPE structure and performance in field conditions, ensuring durable and reliable protection for pipeline joints.

HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 0 HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 1 HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 2
Structure and Composition

The heat shrink sleeve is composed of two primary layers:

  • Radiation Cross-linked Polyethylene (PE) Backing - Offers superior mechanical strength and protection from external damage.
  • Special Hot-Melt Adhesive Layer - Ensures strong adhesion to the steel surface and seamless bonding with the epoxy primer.

This system is applied in conjunction with a solvent-free two-component epoxy primer, forming a true 3-layer field-applied coating system.

HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 3
Installation Process
  1. Surface Preparation - Clean and prepare the steel surface at the weld joint area.
  2. Epoxy Primer Application - Apply the solvent-free two-component epoxy primer.
  3. Sleeve Application - Wrap the heat shrink sleeve over the wet primer.
  4. Heat Shrinking - Apply heat to shrink the sleeve tightly around the joint.
  5. Curing and Protection - The epoxy cures, creating strong chemical and mechanical bonds.
Application Areas
  • Field joint corrosion protection for oil and gas pipelines
  • Field joint corrosion protection for water pipelines
  • Repair and maintenance of factory-applied 3LPE coatings
HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 4 HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 5
Key Features
  • Material: High-quality PE
  • Ensures secure heat shrink sealing for pre-insulated steel pipe field joints
  • Available in standard or customized options
  • Standard black, with customized alternatives upon request
  • Easy installation using a gas gun
  • 110-2000mm to fit various pipeline dimensions
  • High production capacity (2000 sets/day)
  • Reliable performance and long-lasting protection
HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 6 HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 7 HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 8
Technical Specifications
PE Backing Layer
Test Item Unit Requirement Result Test Method
Tensile Strength MPa ≥17 19.47 ASTM D638
Elongation % ≥400 626 ASTM D638
Vicat Softening Point ºC ≥90 92 ASTM D1525
Brittleness Temperature ºC < -65 < -65 ASTM D2671C
Dielectric Strength MV/m ≥25 33.13 ASTM D149
Volume Resistivity Ω*m ≥1×10¹³ 1.1×10¹³ ASTM D257
Environmental Stress Crack Resistance h ≥1000 >1000 GB/T 1842
Chemical Resistance
Chemical Test Item Requirement Result
10% HCl Tensile Strength ≥85% 104.9 MPa
Elongation ≥85% 96.3%
10% NaOH Tensile Strength ≥85% 102.1 MPa
Elongation ≥85% 95.6%
10% NaCl Tensile Strength ≥85% 108.3 MPa
Elongation ≥85% 94.1%
Thermal Aging (150 ºC, 168h)
Test Item Requirement Result
Tensile Strength ≥14 MPa 20.7 MPa
Elongation ≥300% 630%
HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 9 HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 10 HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 11
Adhesive Layer Specifications
Test Item Unit Requirement Result Test Method
Softening Point ºC ≥90 90.1 ASTM E28
Brittleness Temperature ºC < -15 < -15 ASTM D2671C
Lap Shear Strength MPa ≥1.0 1.5 ASTM D1002
Peel Strength (23±2ºC) N/cm ≥70 Steel: 145.6
Primer: 205.9
PE Layer: 190.0		 ASTM D1000
Epoxy Primer Specifications
Test Item Requirement Result Method
Shear Strength of Cured Primer ≥5.0 MPa 12 MPa SY/T0041
Compliance Standards

This product complies with major national and international standards, including:

  • GB/T 23257-2009
  • SY/T 4054-2003
  • EN 12068
  • DIN 30672
  • GOST R51164-98
Product Forms & Ordering Information

A complete product set includes:

  • Heat shrink sleeve
  • Closure patch
  • Individually packed epoxy primer

Maximum Operating Temperature: 60 ºC

Available formats:

  • Pre-cut sleeve with separate closure patch
  • Tubular sleeve
  • Roll tape (closure patch ordered separately)
Pre-Cut Sleeve Specifications (Customizable)
Pipe Size (mm) Sleeve Length (mm) Patch Length (mm) Patch Width (mm)
Φ159 × 500 670 500 80
Φ219 × 500 860 500 100
Φ273 × 500 1000 500 100
Φ325 × 500 1200 500 100
Φ355 × 500 1300 500 100
Φ406 × 500 1460 500 120
Φ508 × 500 1800 500 120
Φ610 × 500 2170 500 120
Φ711 × 500 2500 500 150
Φ813 × 500 2880 500 150
Φ1016 × 500 3480 500 150
Φ1219 × 500 4120 500 200
Φ1420 × 500 4780 500 200
Roll Tape Specifications (Customizable)
Width (mm) Standard Length Thickness
100-600 5m, 10m, 15m, 20m, 30m per roll PE Layer: 1.2 mm
Adhesive Layer: 0.8 mm
Why Choose HUASHIDA?
  • 20+ Years of Manufacturing Experience
  • Exported to Global Markets
  • Trusted Quality and International Reputation
  • Participation in Major Industry Exhibitions
  • Modern Production Facilities
  • Professional Technical Team
HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 12 HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 13 HDPE Heat Shrink Sleeve For 3LPE Pipeline Joint Protection 14
