Steel Pipe 3PE / FBE insulation anticorrosion production line
Product Description
Steel pipe anti-corrosion coating line is used for anti-corrosion coating steel pipe in the factory with various diameter, which is much more extensively across a diverse range of engineering construction projects, especially in the heating, gas, oil field.
The lines can be applied to FBE, 2 layer FBE, 2 layer PE, 2 layer PP and 3 layer PE anti-corrosion coating.
3 layer PE anti-corrosion coating consists of first FBE coating, middle adhesive layer and outer polyethylene layer.
Steel Pipe 3LPE Anti-corrosion Coating Line (Dia. 159-4200mm)
![Steel Pipe 3lpe 3PE Fbe Vus Insulation Anticorrosion Coating Line]()
![Steel Pipe 3lpe 3PE Fbe Vus Insulation Anticorrosion Coating Line]()
Steel Pipe Internal & External FBE Coating Line (Dia. 50-4200mm)
Internal FBE External 3LPE Coating Line (Dia. 159-4200mm)
Small Size Steel Pipe O-type Extrusion 3LPE Coating Line (Dia. 50-426mm)
Steel Bend pipe FBE &3LPE coating Production Line (HSD 426-820mm)
Application
The three-layer polyethylene anti-corrosion coating is advanced technology as the outer protective layer of buried pipe, widely used in the anti-corrosion of gas and oil transmission pipeline, urban gas supply, water supply pipe and other fluid transmission pipeline. 3 layer PE anti-corrosion coating can strengthen the pipeline's mechanical properties with high electrical resistance, waterproof, wearable and anti-aging performance.
Detailed Photos
The anti-corrosion coating processing line includes:
→Steel pipe transmission system
→Surface treatment system
→Pipe dust removal system
→Pipe heating system
→Electrostatic spraying system
→Coating system
→Water cooling system
→End cutting system
→Hydraulic and pneumatic system
→Testing system
→Electronic control system.
Technological processes
Shot Blasting Line: Steel Pipe in →Transfer pipe to Internal High-Pressure Blowing ( with Dust collector) and water washing →Transfer to external High-Pressure Water Washing→Gas oven preheating →External Shot Blasting (with Dust collecting) → Internal high pressure Blowing ( with Dust collector)
Coating Line: Loading onto 3LPE conveyor after blasting→High pressure blower→IF Heating →Automatic Powder Feeding→FBE Powder Coating(with Dust collector)→AD Adhesive powder Spraying→PE Wrapping → Water Cooling → Coating Inspection→Both Ends PE Layer Turning and Grinding→Holiday Inspection→ External Marking Application→Packaging and Offline Loading
Our Advantages
Core Advantages of the Equipment
→Small dimension,suitable for various venues, enabling flexible deployment
→High degree of automation, can be operated by one person, saving labor costs
→Long service life, low maintenance cost
→Equipped with a high-efficiency extruder, ensuring sufficient output and stable performance
→Uniform wall thickness of pipes, smooth surface, good forming effect and controllable quality
→High raw material utilization rate
→One-time forming process, no need for additional trimming
Service and Guarantee
→Provide a one-stop complete production solution includes design, installation, commissioning and training
→With a total of 389 sets of practical production line experience worldwide, we boast mature technology and strong implementability, and are ready to share
→Set up a professional technical team with professional senior engineers to provide full-process technical support
→Our company has a high-end expert workstation for plastic machinery equipment in China
Main Equipment List
| No. |
Name |
Set |
| A. Derusting Equipment |
| 1 |
Pipe wheel conveyor |
1 |
| 2 |
Shot Blasting Machine |
1 |
| 3 |
Cyclone Dust Collector |
1 |
| 4 |
Pulse dust collector |
1 |
| 5 |
Centrifugal exhaust fan |
1 |
| 6 |
Rust removal equipment PLC |
1 |
| B. Coating equipment |
| 1 |
Pipe wheel conveyor |
1 |
| 2 |
Induction heating device |
1 |
| 3 |
Powder spraying device |
1 |
| 4 |
Automatic loading dryer |
2 |
| 5 |
SJ-65/30 Extruder |
1 |
| 6 |
SJ-120/30 Extruder |
1 |
| 7 |
Hot melt adhesive extruder die |
1 |
| 8 |
PE sheet extruder head mold |
1 |
| 9 |
Hot melt adhesive/PE sheet coating device |
1 |
| 10 |
Environmental Protection Ventilation equipment |
1 |
| 11 |
Cooling Spray equipment |
1 |
| C.Platform Equipment |
| 1 |
Steel pipe uploading platform |
1 |
| 2 |
Downloading platform |
1 |
| 3 |
Pipe storage platform |
1 |
| 4 |
Turnover machanism |
3 |
| D.Groove Equipment |
| 1 |
PE Beveling Machine |
2 |
| 2 |
Hydraulic Lifting and Turning Machinery |
1 |
| 3 |
Hydraulic Equipment |
1 |
| 4 |
PLC automatic control system |
1 |
Product Parameters
1. Pipe diameter: 50-4200mm
2. Processing capacity: ≥250m2/h
3. Cleaning level: ≥Sa2.5
4. Materials for production: epoxy powder, adhesive, polyethylene
![Steel Pipe 3lpe 3PE Fbe Vus Insulation Anticorrosion Coating Line]()
Customer cases
![Steel Pipe 3lpe 3PE Fbe Vus Insulation Anticorrosion Coating Line]()
