3PE 3-Layer PE Polyethylene Steel Pipe Anticorrosion Coating Processing Line

3PE 3-Layer PE Polyethylene Steel Pipe Anticorrosion Coating Processing Line


Description

The coating technology allows to obtain the anticorrosive three-layer polyethylene/polyetylene coating, which consist of:Epoxy layer,copolymer layer (bonding agent),polyethylene/polypropylene layer.

Anticorrosive coating 3LPE/ 3LPP according to PN-EN ISO 21809-1 is composed of:
Epoxy layer of minimum 125 μM thickness,
Copolymer layer of minimum 150 μM thickness,
Polyethylene or polypropylene layer from 1,8 mm to 4,7 mm.

Main Equipment List

The three-layer polyethylene anti-corrosion coating is advanced technology as the outer protective layer of buried pipe, widely used in the anti-corrosion of gas and oil transmission pipeline, urban gas supply, water supply pipe and other fluid transmission pipeline. 3 layer PE anti-corrosion coating can strengthen the pipeline's mechanical properties with high electrical resistance, waterproof, wearable and anti-aging performance.

Q1. What is Size of Pipe Dia. your equipment can produce ?
A: We can produce four main Model:
Diameter of steel tube:
48-219mm.
219-1220 - mm
800-1600 - mm
1000-2400 - mm

Q2. What is Descaling grade?
A:SA2.5?
Q3. What is Delivery Time
A: 2-3monthes
After-sales service:
Warranty period:
The mechanical part warranty is 12 months from the date of pick-up, and the electrical part is 6 months.
Service:
The seller provides free technical services and provides training and guidance to buyer operators.
